02018OT3V256TC-SG WEG AC Motors
Part#:02018OT3V256TC-SG
Manufacturer:WEG
Alt. Part#:7909265723057
Product Lifecycle:Active
Get a quick Quote!
Rolled Steel NEMA Premium Efficiency 20 HP 4P 254/6TC 3Ph 200/400 V 60 Hz IC01 - ODP - Foot-mounted
Check out the 02018OT3V256TC-SG WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating20 HP
- Rated Speed1770 rpm
- Number of Poles4 Pole
- Voltage200/400 V
- Flange TypeC
- LRC 6.3x(Code G)
- Noise level² 64.0 dB(A)
- Number of Poles 4
- Insulation Class F
- Mounting F-1
- Rated voltage 200/400 V
- Design B
- Altitude 1000 m.a.s.l.
- Rated current 57.5/28.8 A
- Moment of inertia (J) 2.23 sq.ft.lb
- Enclosure IC01 - ODP
- Flange C
- No load current 26.3/13.1 A
- Approx. weight³ 228 lb
- Synchronous speed 1800 rpm
- Rated speed 1770 rpm
- Temperature rise 80 K
- Number of poles 4
- Breakdown torque 290 %
- Frequency 60 Hz
- Service factor 1.15
- Standard NEMA MG-1
- Slip 1.67 %
- Locked rotor torque 240 %
- Starting Method Direct On Line
- Terminal box¹ Left position
- Frame 254/6TC
- Output 20 HP (15 kW)
- Rated torque 59.3 ft.lb
- Rotation¹ Both (CW and CCW)
- Output rating 20 HP
- Ambient temperature -20°C to +40°C
- L. R. Amperes 362/181 A
- Locked rotor time 27s (cold) 15s (hot)
- Duty Cycle Cont.(S1)
- Voltage 200/400 V
