BJA260405 Schneider Electric Industrial Automation Components

Name: BJA260405
Brand: Schneider Electric

Schneider Electric BJA260405 Schneider Electric - BJA260405

Part#:BJA260405

Manufacturer:Schneider Electric

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric - BJA260405

About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the BJA260405 Schneider Electric price in the box on the right side or send a quick quote.

Product Details

Local Signalling
for presence of auxiliary contacts flag (green)
Height
5.39 in (137 mm)
Continuous Current Rating
80 %
Line Rated Current
40 A
Mounting Height
3.00 in (76.2 mm)
Phase Connection
CA
Control Type
Toggle
[Ui] Rated Insulation Voltage
800 V IEC 60947-2
Quantity Per Set
Set of 1
Product Or Component Type
Circuit breaker
Device Application
Distribution
Electrical Durability
10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
9 Mm Pitches
6
Color
Grey (RAL 7016)
Number Of Poles
2P
[Uimp] Rated Impulse Withstand Voltage
8 kV IEC 60947-2
Mounting Mode
I-Line
Device Short Name
BJ 040
Suitability For Isolation
Yes IEC 60947-2
Net Weight
2.10 lb(US) (0.952 kg)

Product Name

PowerPact B

[Ue] Rated Operational Voltage

690 V AC 50/60 Hz UL 489

Connection Pitch

1.06 in (27 mm)

Width

2.13 in (54 mm)

Range

PowerPact

Trip Unit Technology

Thermal-magnetic

AWG Gauge

AWG 14...AWG 2/0 aluminium/copper

Depth

3.50 in (89 mm)

Breaking Capacity Code

Mechanical Durability

20000 cycles IEC 947-1 Annex K ed 5.2

Power Wire Stripping Length

0.79 in (20 mm)

Utilisation Category

Category A

Electrical Connection

I-Line connection line Lugs load

Number Of Slots

1 auxiliary switch OF plug-in) 1 voltage release MN or MX plug-in)

Tightening Torque

31.86…38.94 lbf.in (3.6…4.4 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 44.25…54.87 lbf.in (5…6.2 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)

[Ics] Rated Service Breaking Capacity

100 kA 220...240 V AC 50/60 Hz IEC 60947-2 25 kA 500...525 V AC 50/60 Hz IEC 60947-2 2.5 kA 690 V AC 50/60 Hz IEC 60947-2 65 kA 380...415 V AC 50/60 Hz IEC 60947-2 65 kA 440 V AC 50/60 Hz IEC 60947-2

Breaking Capacity

100 kA 208Y/120 V AC 50/60 Hz UL 489 100 kA 240 V AC 50/60 Hz UL 489 65 kA 480/277 V AC 50/60 Hz UL 489 65 kA 480 V AC 50/60 Hz UL 489 25 kA 600Y/347 V AC 50/60 Hz UL 489 50 kA 250 V DC UL 489

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

Related documents BJA260405 Specs

BJA260405 Product Datasheet-1631036729578.pdf

BJA260405 Instruction Sheet-1631036729571.pdf

BJA260405 Catalog-1631036729580.pdf
