SLG 415I-E/R0800-03-12 Schmersal Electronic Components
Part#:SLG 415I-E/R0800-03-12
Manufacturer:Schmersal
Alt. Part#:101170467
Product Lifecycle:Discontinued
Get a quick Quote!
Safety light grids and curtains (Archive); Safety light grids (archive); Control Category 4; NOTICE: Not available! (Replacement: SLG 425I)
About the manufacturer: Schmersal is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the SLG 415I-E/R0800-03-12 Schmersal price in the box on the right side or send a quick quote.
Product Details
- Override Yes
- Restart interlock (manual reset) Yes
- Range, protection field, maximum 16,000 mm
- Degree of protection IP65 to EN 60529
- Electrical power consumption of the receiver 6 W
- Beam distance 400 mm
- Integral System Diagnostics, status Yes
- Wave length of the sensor 950 nm
- Ambient temperature, minimum +0 °C
- Switching voltage OSSD, HIGH signal 24 V
- Muting function Yes
- Beam coding available Yes
- Range, protection field, minimum 0 mm
- Length of sensor 50 mm
- Electrical power consumption of the transmitter 3 W
- Design of multi-ray photoelectric barrier Emitter and receiver, separated
- Height of the protection field 810 mm
- Width of sensor 60 mm
- Ambient temperature, maximum +55 °C
- Standards IEC/EN 61496-1/-2
- Number of semi-conductor outputs with signaling function 1
- Height of sensor 1,076 mm
- Voltage type DC (direct current)
- Reaction time, maximum 7 ms
- Number of beams 3
- Terminal connector, Recipient Connector plug M23, 19-pole
- Storage and transport temperature, maximum +70 °C
- Output current, (fail-safe output), maximum 0.5 A
- Gross weight 7,500 g
- Enclosure material Aluminium
- Number of fail-safe digital outputs 2
- Terminal Connector Connector
- Storage and transport temperature, minimum -20 °C
- Length of cable, maximum 100 m
- Preliminary failure signal Yes
- Integral System Diagnostics Yes
- Terminal, Connector, Transmitter Connector plug M12, 5-pole
- Protection rating III
- Versions p-type
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
