BNS 36 STG-AS-R Schmersal Electronic Components
Part#:BNS 36 STG-AS-R
Manufacturer:Schmersal
Alt. Part#:101194956
Product Lifecycle:Active
Get a quick Quote!
AS interface safety at work; Safety switchgear; 2 m Pre-wired cable with connector M12, straight, 4-pole; Safety sensor; Thermoplastic enclosure; no mechanical wear; 88 mm x 25 mm x 13 mm; Integrated AS-Interface; Concealed mounting possible; Long life; I
About the manufacturer: Schmersal is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the BNS 36 STG-AS-R Schmersal price in the box on the right side or send a quick quote.
Product Details
- Installation conditions (mechanical) quasi-flush
- Repeat accuracy R ≤ 0.1 x Sao
- Coding Yes
- Notice (Switch distance Sn) Axial misalignment, a horizontal and vertical misalignment of the safety sensor and the actuator are tolerated. The possible misalignment depends on the distance of the active surfaces of the sensor and the actuator. The sensor remains active within the t
- Gross weight 110 g
- Storage and transport temperature, maximum +70 °C
- Ambient temperature, minimum -25 °C
- Degree of pollution to VDE 0100 3
- Door hinge Right
- Wire cross-section 0.23 mm2
- Overvoltage category III
- AS-i, IO-Code 0x0
- AS-i Input module address 0
- Reaction time, maximum 100 ms
- Ambient temperature, maximum +60 °C
- Note (AS-i Operating voltage) Protection against polarity reversal
- AS-i, ID-Code 0xB
- Active principle Magnetic drive
- Ensured switch distance ON Sao 7 mm
- AS-i Operating voltage, minimum 18 VDC
- AS-i Profile S-0.B.F.E
- AS-i Outputs, DO 0 … DO 3 No Function
- Actuating element Magnet
- Enclosure material Glass-fibre, reinforced thermoplastic
- Storage and transport temperature, minimum -25 °C
- AS-i, ID-Code2 0xE
- Standards IEC 61508, IEC 60947-5-3, EN 62026-2
- Length of sensor 13 mm
- Rated impulse withstand voltage Uimp 0.8 kV
- AS-i Specification Safety-Slave
- AS-i Input, Channel 2 Data bits DI 2 / DI 3 = dynamic code transmission
- Length of cable 2 m
- Height of sensor 25 mm
- AS-i Operating voltage AS-i maximum 31.6 VDC
- AS-i Version V 2.1
- AS-i Parameter bits, P0 ... P3 No function
- Integral System Diagnostics, status Yes
- Direction of motion Head-on to the active surface
- Terminal Connector Connecting cable with M12 connector, straight, 4-pole
- Material of the Cable mantle LSYY
- Degree of protection IP67 to EN 60529
- Restistance to shock 30 g / 11 ms
- Rated insulation voltage Ui 32 VDC
- AS-i, ID-Code1 0xF
- Note (AS-i Parameter bits) Set the parameter outputs to "1111" (0xF)
- Note (AS-i Input module address) Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
- Ensured switch distance OFF Sar 17 mm
- Resistance to vibrations to EN 60068-2-6 10 … 55 Hz, amplitude 1 mm
- AS-i Current consumption, maximum 50 mA
- AS-i Input, Channel 1 Data bits DI 0 / DI 1 = dynamic code transmission
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents BNS 36 STG-AS-R Specs
