W1016642 Mersen Fuse Holders
Part#:W1016642
Manufacturer:Mersen
Alt. Part#:3605340505405
Product Lifecycle:Active
Get a quick Quote!
W1016642 Mersen - Fuse Holder Modulostar® Size 22x58 IEC 690VAC 690VDC 1-Pole+N IP20 With Microswitch
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the W1016642 Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles1+N Pole
- Current Rating125 A
- Weight433.57 g
- Design Details CMS22 single pole + neutral conductor
- Rated Insulation Voltage 690 V
- Sell Pack Quantity 3 EACH
- Rated voltage AC IEC 690 V
- ROHS Compliant Yes
- Installation Mounting DIN rail acc. EN 60715
- Sell Pack Height 3.35 in
- Fuse Size 22x58
- Rated Impulse Withstand Voltage 8
- Sell Pack Width 5.31 in
- Indication System Yes
- Number of Poles 1-Pole+N
- Sell Pack Weight 2.866 lb
- Ampere Rating 125 A
- Conventional Free Air thermal Current With Fuse-Links Ith 125 A
- Product Height 5.02 in
- Rated voltage DC IEC 690 V
- Torque Rating 35.4 lb-in
- Comments Wiring tool : PZ2 or flat 6.5x1.2mm screw drivers recommended (max. diameter 7mm)
- Sell Pack Length 9.25 in
- Catalogue No. CMS221NM
- Product Weight 0.955 lb
- Product Length 3.01 in
- Short Circuit Current Rating (SCCR) 100 kA
- Indication System Type Microswitch
- Product Width 2.76 in
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
W1016642 Description
W1016642 Mersen - Fuse Holder Modulostar® Size 22x58 IEC 690VAC 690VDC 1-Pole+N IP20 With Microswitch | The innovative and comprehensive Modulostar® range of Mersen fuse-holders. Modular fuse-holders are finger-safe under IEC standards to an IP20 grade of protection, including fuse changing (with the flick of a finger). Modular fuse-holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicator, in IEC version or IEC + UL version. Multi-pole units can also be field assembled by ordering pin-ties assembly kit. In size 14 or 22, the range also offers the possibility to use microswitches (supplied with the holders or ordered separately) to allow remote indication. Modulostar® range is made of tough and durable thermoplastic or thermoset material. | Features: *Finger safe
*Degree of protection: IP20
*Optional visual blown fuse indicator
*DIN rail mounting
*Modular design
*Lockable
*Multi-pole assembly kit available
*Sealable in closed and open position
*Plastic material UL94V2 mini
*Flame retardant materials with glow wire flammability index to 960°C
*Shock and vibration tested for marine and railway applications | Application: *All circuits up to 690V for protection of motors, transformers, low voltage distribution, control circuits.
*Non-load operation
Related documents W1016642 Specs
