N226424 Mersen Fuse Holders

Mersen N226424 N226424 Mersen - Fuse Holder UltraSafe™ 800VAC 800VDC UL Fuse size 27x60 3-Pole+N Visual Indicator Faston Lugs IP20
Mersen

Part#:N226424

Manufacturer:Mersen

Alt. Part#:3605340269086

Product Lifecycle:Active

Get a quick Quote!

N226424 Mersen - Fuse Holder UltraSafe™ 800VAC 800VDC UL Fuse size 27x60 3-Pole+N Visual Indicator Faston Lugs IP20

About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the N226424 Mersen price in the box on the right side or send a quick quote.

Product Details

  • Number of Poles3+N Pole
  • Current Rating140 A
  • Voltage800 VAC
  • Weight303.272 g
  • Indication System
    Yes
  • ROHS Compliant
    Yes
  • Design Details
    triple pole + neutral conductor
  • Max Power dissipation of Fuse Links Pn
    11 W
  • Sell Pack Width
    6.1 in
  • Ampere Rating
    140 A
  • Number of Poles
    3-Pole+N
  • Product Weight
    0.668 lb
  • Rated voltage AC UL
    800 V
  • Fuse Size
    27x60
  • Conventional Free Air thermal Current With Fuse-Links Ith
    140 A
  • Sell Pack Weight
    0.668 lb
  • Rated voltage DC IEC
    800 V
  • Installation Mounting
    DIN rail acc. EN 60715
  • Product Width
    6.3 in
  • Rated voltage DC UL
    800 V
  • Indication System Type
    Visual Indicator
  • Sell Pack Quantity
    1 EACH
  • Rated Insulation Voltage
    800 V
  • Comments
    Wiring tool : PZ3 or flat 8x1.2mm screw drivers recommended
  • Rated voltage AC IEC
    800 V
  • Rated Impulse Withstand Voltage
    8
  • Product Height
    5.88 in
  • Catalogue No.
    US273NI
  • Torque Rating
    30.98 lb-in
  • Product Length
    3.68 in
  • Sell Pack Height
    3.94 in
  • Sell Pack Length
    6.5 in

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

N226424 Description

N226424 Mersen - Fuse Holder UltraSafe™ 800VAC 800VDC UL Fuse size 27x60 3-Pole+N Visual Indicator Faston Lugs IP20 | The innovative and comprehensive Modulostar® range of Mersen

fuse-holders.

Modular fuse-holders are finger-safe as per IEC standards to an IP20

grade of protection. Including fuse changing, with the flick of a finger.

Modular fuse-holders are available in 1, 2 or 3 poles, with or without

visual blown fuse indicators, in IEC + UL version.

Multi-pole units can also be field assembled by ordering pin-ties

assembly kit. The range offers the possibility to use microswitches

(supplied with the holders or ordered separatly) to allow remote

indication. Modulostar® range is made of tough and durable

thermoplastic or thermoset material. | Features: *Finger safe

*Degree of protection: IP20

*Optional visual blown fuse indicator & microswitch

*Designs available for DIN rail mounting and direct mounting on board

*Modular design

*Multi-pole assembly kit available

*Plastic material UL94V2 mini

*Flame retardant materials with glow wire flammability index to 960°C | Application: *All circuits up to 800V using semiconductor fuses for protection of small inverters, UPS systems, motor drives, etc.

*Non-load operation

Related documents N226424 Specs

N226424 E1A24E2BBCA9417890405048F79C4F22-1en.pdf
