SBN232 ifm Electronic Electronic Components

Product Details

• Medium temperature [°F]
  14...212
• Pressure rating [Mpa]
  4
• Number of analog outputs
  1
• Pressure rating [bar]
  40
• Reverse polarity protection
  yes
• Note on media
  oil 1 with viscosity: 10 mm²/s (40 °C) oil 2 with viscosity: 46 mm²/s (40 °C)
• Permanent current rating of switching output DC [mA]
  150; (per output 2 x 200 (...60 °C); 2 x 250 (...40 °C))
• Process connection
  threaded connection 3/4" NPT
• Protection class
  III
• Short-circuit protection
  yes
• Power-on delay time [s]
  < 3
• Max. voltage drop switching output DC [V]
  2
• Number of digital outputs
  2
• Overload protection
  yes
• Media
  water; glycol solutions; Coolants; oils
• MAWP (for applications according to CRN) [bar]
  40
• Output signal
  switching signal; analog signal; frequency signal; IO-Link; (configurable)
• Frequency of the output [Hz]
  0...10000
• Max. load [Ω]
  500
• System
  gold-plated contacts
Operating voltage [V]
18...30 DC; (according to EN 50178 SELV/PELV)
Output function
normally open / closed; (configurable)
Measuring range
5...240 gph 0.1...4 gpm
Application
for industrial applications
Total number of outputs
2
Analog current output [mA]
4...20
Current consumption [mA]
< 50
Number of inputs and outputs
Number of digital outputs: 2; Number of analog outputs: 1
Switching cycles (mechanical)
10 million
