548400 Eriflex Insulators

Eriflex 548400 548400 Erico - Low Voltage Metric Insulator, F-F, ISO TP 15M4, Height: 0.59", Depth: 0.63", Diameter: 0.47", Thread size: M4, Static load: 337lb
Eriflex

Part#:548400

Manufacturer:Eriflex

Alt. Part#:ISOTP15M4

Product Lifecycle:Active

Get a quick Quote!

548400 Erico - Low Voltage Metric Insulator, F-F, ISO TP 15M4, Height: 0.59", Depth: 0.63", Diameter: 0.47", Thread size: M4, Static load: 337lb

About the manufacturer: Eriflex is one of the manufacturers that offers Insulators that you can order at marketplace.quotebeam.com. Low voltage power and grounding connections are available for OEMs, panel builders, and specific industries.

Check out the 548400 Eriflex price in the box on the right side or send a quick quote.

Product Details

  • Height0.59 in
  • Thread SizeM4

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

548400 Description

548400 Erico - Low Voltage Metric Insulator: Compact, Reliable, and Efficient

The 548400 Erico Low Voltage Metric Insulator is a compact and durable solution designed for applications requiring precision and safety in electrical installations. With its robust construction and advanced material properties, this insulator ensures reliable performance in demanding environments.

Key Features

Halogen-Free Design: Reduces risks associated with toxic emissions during high-heat situations.

Exceptional Leakage Current Resistance: Ensures safety and reliability in electrical systems.

Stable Electrical and Mechanical Parameters: Provides consistent performance over time.

Fiberglass Reinforced Construction: Offers lightweight strength and durability for compact applications.

UL® Recognized Certification: Rated for dielectric withstand up to 1,500 VAC/DC, meeting E125470 standards.

RoHS Compliant: Supports environmentally sustainable practices and global safety standards.

Specifications

Dielectric Strength: UL 1,500

Finish: Electrogalvanized for enhanced corrosion resistance

Material: Steel with Glass Fiber Reinforced Polyamide for durability

Compliance: IEC® 60695-2-11 Glow Wire Test at 960 °C for fire safety

Flammability Rating: UL® 94V-0 for reduced flammability risk

Working Temperature Range: -40°F to 266°F, suitable for a wide range of conditions

Dimensions:

Height: 0.59"

Depth: 0.63"

Diameter: 0.47"

Thread Size: M4

Static Load Capacity: Supports up to 337 lbs.

Why Choose the Erico 548400 Metric Insulator?

This compact insulator is designed for precision applications where space and performance are critical. Its halogen-free and RoHS-compliant design ensures safety, while its high resistance to leakage current makes it a reliable choice for sensitive systems. The fiberglass-reinforced material provides excellent strength and stability in a small form factor.

Applications

Low-voltage electrical installations

Compact control panels and systems

Lightweight electrical compon
